UT-910G-XX00
10G SFP+ SR MMF 850nm 300m
Copy to clipboard
Scope of Application

The LINK SFP+ transceivers are high performance, cost effective modules which is the best for all 10G network interface, The UT-910G series can install into Switch products with SFP+ interface and can be compatible with Cisco & others brand.


LINK 10G SFP+ transceivers provide extended connectivity up to 300m (OM3) or 400m (OM4) transmission
distance with Multi-mode fiber (MM).


LINK SFP+ transceivers are a hot-pluggable (or hot-swappable). You can plug-in and out the transceiver to/from any SFP+ port without having to power down the network devices.

Technical Standard

• Hot-Pluggable and support data rate up to 10Gbps
• Compliant with IEEE802.3ae 10Gigabit Ethernet standard
• Compliant with Fiber Channel standard
• Support STM-16/64
• Compliant with SFP+ Multi Source Agreement (MSA)
• 850nm VCSEL transmitter, PIN photo-detector
• Electrical interface compliant to SFF-8431 and SFF-8432
• Class 1 laser and complies with EN 60825-1
• Digital Diagnostic Monitoring Interface (DDMI) Capability
• Diagnostic Monitoring Interface to SFF-8472
• All-metal housing for superior EMI performance
• Low power consumption, Single +3.3V Power supply
• Duplex LC connector
• Operating temperature from 0°C to 70°C
• Cost effective SFP+ solution, enables higher port densities and greater bandwidth
