LAN (UTP) System
|
CAT 6 Ultra 600 MHz LAN Cabling
|
CAT6 UTP ULTRA (600MHz) w/Cross Filler, 23AWG, LSZH
US-9116LSZH
CAT6 UTP ULTRA (600MHz) w/Cross Filler, 23AWG, LSZH
Copy to clipboard







Scope of Application
This specification covers the general requirements for UTP cable used for indoor installation. LINK Ultra Category 6 U/UTP LSZH cables compliant ISO/IEC 11801 Class E and ANSI/TIA-568.2-E requirements for category 6 performance. These cables are characterized to 600MHz, Powersum NEXT tested certified. The outer jacket material made from LSZH compound to reduces the amount toxic smoke and corrosive has emitted during burned, for users’ safety as well as increases the safety of firefighting operations.
Technical Standard
- ANSI/TIA-568.2-E Category 6
- ANSI/TIA-568.2-D Category 6
- ANSI/TIA-568-C.2 Category 6
- ISO/IEC 11801:2017 class E
- EN 50173-1 Category 6
- EN 50288-6-1
- IEC 61156-5, IEC 60332-1
- IEC 60754-1, IEC 60754-2
- IEC 61034-1, IEC 61034-2
- ICEA S-102-700 Category 6
- ASTM D4566-98
- NEMA WC 66
- UL 444
- CSA 22.2 No.214
- ETL and 3P Verified to Category 6
- Intertek Certification no. 104047595CRT-001
- RoHS Compliant
