Product | LAN (UTP) System | CAT 6 Ultra 600 MHz LAN Cabling |

CAT6 UTP (250MHz) w/Cross Filler, 24AWG, CM

PRODUCTS
US-9106A
CAT6 UTP (250MHz) w/Cross Filler, 24AWG, CM
Copy to clipboard
Scope of Application

This specification covers the general requirements for UTP cable used for indoor horizontal installation. LINK Category 6 U/UTP cables compliant with ISO/IEC 11801 Class E and ANSI/TIA-568.2-E requirements for category 6 performance. These cables are characterized to 250MHz, Powersum NEXT tested. The cable covered under UL certification which the UL mark E197771 appearing on the cable jacket.

Technical Standard
  • ANSI/TIA-568.2-E Category 6

  • ANSI/TIA-568.2-D Category 6

  • ANSI/TIA-568-C.2 Category 6
  • ISO/IEC 11801:2017 class E
  • EN 50173-1 Category 6
  • EN 50288-6-1
  • IEC 61156-5
  • ICEA S-102-700 Category 6
  • ASTM D4566-98
  • NEMA WC 66
  • UL 1685
  • UL 444
  • CSA 22.2 No.214
  • UL Verified to Category 6
  • Approvals UL listed file no. E197771
  • RoHS Compliant
