AC 1200 Mbps Wave 2 Dual Band, Ceiling Gigabit ACCESS POINT w/PoE

PRODUCTS
PA-3120A
AC 1200 Mbps Wave 2 Dual Band, Ceiling Gigabit ACCESS POINT w/PoE
Copy to clipboard
Scope of Application

The PA-3120A is a gigabit dual-band ceiling access point which support IEEE 802.11AC Wave 2. It offers a concurrent data rate as high as of 1167 Mbps. Powered by MU-MIMO technology, a single PA-3120A can simultaneously communicate with multiple clients, greatly improving the throughput and bettering user experience. The built-in omni-directional antennas optimize signal radiating directions, broadening the wireless coverage of a single AP.

PA-3120A can be powered by PoE sourcing equipment that compliant with IEEE 802.3af/at. With its ceiling installation design and sleek appearance, it simplifies wireless networking for enterprises, hotels and other public indoor spaces.

Technical Standard

• IEEE 802.11a/b/g/n/ac compliant
• Support IEEE802.3af/at
• Up to 1167 Mbps dual-band data rate
• 1 x Gigabit RJ45 port with PoE
• Extend WiFi coverage area
• MU-MIMO which enable communication over 2:2
spatial streams for high throughput
• Support Web UI configuration
• Support wireless clients roaming to automatically
connect to AP with a better signal
