This specification covers the construction and properties of Mini ARSS (Anti-Rodent Self-Support), Outdoor, 3 Twisted-tube, Single Jacket, fiber optic cable for aerial, direct buried and duct installation. LINK fiber optic cable supports application such as 25/40/50/100/200/400Gbps Ethernet, IEEE802.3ae 10G Ethernet, IEEE802.3z Gigabit Ethernet, IEEE802.3u Fast Ethernet, 52/155/622Mbps, 1.2Gbps ATM, FDDI, Fiber channel, FTTx, CATV, CCTV and others. LINK Mini ARSS, Outdoor, 3 twisted-tube, Single Jacket, Fiber optic cable. Single-mode color coded fibers are housed in multiple color coded plastic loose tubes and filler rod which are stranded around central strength member. Dry water blocking yarns, provide protection against water ingress. These user friendly elements replace the sticky cable filling gel used in traditional loose tube cable designs. FRP which provide tensile strength. Water blocking E-glass yarns provide for additional strength member and water blocking. Corrugated steel tape provide for anti-rodent protection. The cable sheath is high density polyethylene jacket which contain 4 to 24 cores.

ANSI/TIA-568.3-D
ANSI/TIA-568-C.3
ANSI/ICEA 640
Telcordia (Bellcore) GR-20-CORE
ITU-T G.652D (Singlemode)
ITU-T G.651 (Multimode)
ISO/IEC 11801:2011
ISO/IEC 11801:2017
IEC 60793, IEC 60794-1-2
EN 50173-1
TIS 2166-2548
RoHS Compliant
